27C64, 27C128, 27C256, 27C512, 27C010, 27C020, 27C040,27C1001
M27C1001, M27C2001, M27C4001
27C080 (A19) ,M27C801,M87C257
2716(Vpp25V),2732, (adapter DIP24)
2764, 27128, 27256, 27512, 27010,
Vpp12.5V (21Vpp Modify Circuit)

EEPROM

28C65,28C64, 28C128, 28C256,28C512, 28C010, 28C020, 28C040
M28C16A/17A (DIP28)
(Adapter or Jumper) 28C16,XLS2816 (DIP24)

FLASH Memory

28F64, 28F128, 28F256, 28F512,28F010, 28F020
MX26C1000, MX26C2000, MX28F1000, MX28F2000
Am28F256A, Am28F512A, Am28F010A, Am28F020A (New command erase/prog.)
-- intel ---
i28F001BX, 28F004, 28F008, 28F016

FLASH Memory

29F64, 29F128, 29F256, 29F512,29F010, 29F020, 29F040, 29F080
29F001,29F002, 29F004, 29F008, 29F016, 29F032

Serial (I2C) EEPROM
24Cxx

24C02,24C04,24C08,24C16, 85C72, 85C82, 85C92
--- page write ----
24C32,24C64,24C128,24C256,24C512

Microwire EEPROM

<------ Data 8bit -----> (pin 6 ->ORG. [Schematic connect to GND])
93C06, 93C46, 93LC46, 93C56, 93C57,
93C66, 93C76, 93C86 (8bit), AT59C11, AT59C22, AT59C13
CAT35C102, CAT35C104, CAT35C108 (pullup pin7)
<------Data 16bit------> (pin 6 ->NC [No Connect])
93C06A ,93C46X,93C56,93C66,93C76,93C86 (NS)

MicroChip PIC

16C84, 16F84, 16F84A ,16F627/16F628
12C508/A, 12C509/A, 12CE518, 12CE519, 16C505
16C620 16C621, 16C622, 16CE623, 16CE624, 16CE625, 16C710/711
PIC 16F818/819
---ICSP connector----
16F870, 16F871, 16F872, 16F873, 16F874, 16F876, 16F877
PIC16F873A, PIC16F874A, PIC16F876A, PIC16F877A

Atmel Flash Memory
(Sector Programming)
(Software Data Protection)

AT29C256, AT29C512,AT29C010A, AT29C020, AT29C040,AT29C040A
W29EE512,W29EE011, W29EE012, W29C020(128),W29C040
PH29EE010(W29EE011) ASD AE29F1008 , AE29F2008
Ver 0.992 up(DOS). Can run under win9x
(disable prog. CPUIdle or CPUCool)

Atmel Flash Memory
AT49Fxxx (Subset 29Fxxx)
(Byte-by-Byte Programming)
(Software Data Protection)

Command seq. 5555/AA, 2AAA/55, 5555/A0
AT49F512, AT49F010, AT49F020, AT49F040
SST39SF010, SST3S9F020 ,SST39SF040
AT49F001,AT49F002 , AT49F008A

Command seq. 555/AA, 2AA/55, 555/A0
Am29F512, Am29F010, Am29F020, Am29F040,HY29F080
29F002, 29F002T, Pm29F002T

Serial Peripheral Interface (SPI)
EEPROM Mode0 (0,0)
AT25xxx, W95xxx

[Atmel] AT25010,020, 040 (A8-A0)
AT25080, 160, 320, 640, 128, 256 (A15-A0)
[ST] W95010....256, Microchip 25x010 - 25x640
--- Byte programming
25010,25020,25040
--- Page programming
25C080,25C160,25C320,25C640,25C128,25C256,25C512
AT25HP256,AT25HP512
AT25HP1024 (24bit address)
-- CAT64LCxxx (16bit DATA IN/OUT) use Socket 93Cxxx
CAT64LC010, CAT64LC020, CAT64LC040

Atmel EEPROM (page prog.)
(Software Data Protection)

AT28C256, AT28C010, AT28C040

Nonvaltile SRAM (DS12xx)

DS1220,DS1225Y, DS1230Y/AB, DS1245Y/AB, DS1249Y/AB

static RAM (Test RAM)

6116, 6264, 62256, 62512, 628128

EPROM winbond,SST
Electrical Erase Chip

W27E512, W27E010, W27C010, W27C020, W27C040
SST27SF256, SST27SF512, SST27SF010, SST27SF020
MX26C4000
Vcc = 3.3-3.6V SST37VF512, SST37VF010, SST37VF020, SST37VF040

Flash Memory SST,Sanyo

SST28SF040A ,LE28F4001

Adapter

Atmel AT89Cxx (MCS-51)
Adapter 32pin to MCS-51

Atmel Auto Setect
AT89C51,52,55, AT89LV51,52,55
AT89S8252 (8K+2K), AT89S53, AT89LS8252,AT89LS53
AT89C1051,AT89C2051,AT89C4051 (20pin)
AT89C51RC (32KB), AT89C55WD (6.2V)
AT89S51, AT89S52
SST89C54/58, SI89C52
Intel Auto Select
i87C51, i87C51FA, i87C51FB
------------------------------------------------
i8xC51,i8xC52,i8xC54,i8xC58 (tWP = 100uS*25 Pulse)

Atmel AVR 8-bit RISC AT90Sxxx
(Parallel programming)
Adapter 32pin to MCS-51

(read,write,erase,verify,checkempty,Lockbits ,Fusebits) [Flash memory/EEPROM]
AT90S1200,AT90S2313
90S2333, 90S4433, 90S4414, 90S8515, 90S4434, 90S8535
reference AT90S2313 pin
Function Lockbit read AT90S2313 Errata Sheet.pdf

MCS-48,MCS-41
Adapter 32pin to MCS-48/41

ROM (read/verify)
P8048AH, P8049AH,P8050AH, P8042AH Vea = 12V
P8041, P8042
OTP (read/verify/Progam)
P8748,P8749H,P8742H Vea = 18V
EPROM (read/verify/Progam)
D8748,D8749,D8742,D8741, D8742 Vea = 18V

FLASH memory 8/16bit
(Software Data Protection)
Adapter (TSOP48)

Am29F400,Am29F800,29F160,29F320 (read,write byte mode)
HY29F200, HY29F400, HY29F800 , AT49F2048A, AT49F4096A, AT49F8192A

FLASH memory 8/16bit (Vpp12V)
(Software Data Protection)
Adapter (TSOP48)

i28F200,i28F400,i28F800,i28F160 (TSOP48)
28F001(DIP32 or PLCC32)

EPROM 16bit (DIP40) (1-4Mbit)
Adapter Eprom 16bit
Eprom only

27C1024 (27C210), 27C2048 (27C2002), 27C4096 (27C4002),
Schematic by Toomas Toots
(read,Program byte mode
by use Resister pull up Data Bus (0xFF), A0 select low or high byte)

EPROM 16bit (DIP42) (4-32Mbit)
Adapter Eprom DIP42
Eprom only

M27C400(DIP40), 27C800, 27C160, 27C322
Schematic by Toomas Toots
(read,Program byte mode
by use Resister pull up Data Bus (0xFF), A0 select low or high byte)

FLASH memory 8/16bit
(Software Data Protection)
Adapter (TSOP48LV)

29LV200, 29LV400,29LV800,29LV160,29LV320 (read,write byte mode)

Firmware Hub / LPC FLASH
Adapter Firmware Hub/LPC (PLCC32) (PP mode) (3.3V)

-- Firmware Hub
82802AB, 82802AC, AT49LW040, AT49LW080

SST49LF002A, SST49LF003A, SST49LF004A, SST49LF008A
W49V002FA, W39V040FA
-- LPC flash
SST49LF020, SST49LF040
W49V002A, W39V040A

P28F002BC
Adapter P28F002BC (DIP40)

BOOT BLOCK FLASH MEMORY
- P28F002BC
